| SPECIFICATIONS: | |
| Model Number | Coleman 200cc |
| ENGINE INFO | |
| Engine type | 4-stroke, single-cylinder, air-cooled |
| Displacement | 196 cc |
| Cooling | Air cooled |
| Max horsepower | 8.3 HP @ 8000 rpm |
| Max torque | 12.0 Nm @ 6500 rpm |
| Bore*stroke | 68 mm × 54 mm (2.68″ × 2.13″) |
| Max speed | 65 km/h (≈ 40 mph) |
| Fuel system | Carburetor |
| Ignition | CDI (Capacitor Discharge Ignition) |
| Starting system | Electric start / Recoil start |
| Battery | 12V, 4Ah |
| Engine oil | SAE 10W-30 (recommended) |
| CHASSIS ETC. | |
| Driveline | Automatic with reverse (F–N–R), chain drive |
| Suspension, front/rear | Independent double A-arm / Swingarm with single rear shock |
| Brakes, front/rear | Hydraulic disc / Hydraulic disc |
| Tires, front/rear | Front: 22×7-10 / Rear: 22×10-10 |
| Fuel capacity/type | 3.6 L / Gasoline |
| Weight, G.W./N.W. | 95 kg / 82 kg (209 lb / 181 lb) |
| DIMENSIONS | |
| Wheelbase | 1150 mm (45.3″) |
| OA LWH | 1700 × 740 × 1000 mm (66.9″ × 29.1″ × 39.4″) |
| Seat Height | 680 mm (26.8″) |
| Min Ground Clearance | 150 mm (5.9″) |
COLEMAN
The Coleman 200cc is a versatile ATV built for riders who need both performance and convenience. Featuring a 200cc four-stroke engine, it delivers smooth power and reliable acceleration across various terrains. The automatic transmission simplifies handling, while its advanced suspension ensures a comfortable ride. Equipped with a LED display, riders can easily monitor essential information at a glance. Front and rear hydraulic disc brakes provide strong stopping power, making it a dependable choice for both work and recreation.
